interactive Whiteboard

The Touch Pro Intelligent Series from is an ultra-slim, frameless interactive Whiteboard designed for modern classrooms and meeting spaces.

Effortless Plug and Play Connectivity

Experience hassle-free setup with our driver-free 10-point touch technology. Simply connect the display to your device and start using it immediately no complex installations, no software downloads, no technical expertise required.

Immersive Edge to Edge Display

Enjoy a stunning visual experience with our ultra-narrow 0.85cm aluminum frame design. The minimal bezel creates a virtually borderless full-screen effect that maximizes your viewing area and delivers a modern, premium aesthetic.

Rounded Corner Design

The thoughtfully engineered rounded corner design eliminates sharp edges, making the display safe for use in high-traffic environments, educational institutions, and family settings.

Anti Light Technology

Powered by our patented, self-developed hardware and firmware, this display delivers exceptional visibility even in challenging lighting conditions.

Premium IR Sensor Reliability

EnjoyBuilt with imported international brand chips, our infrared touch sensors guarantee best-in-class performance and long-lasting durability.

Specifications

Product Specs
Model: R3-900
Touch Size: 86 inch
Frame Size: (1783 2.0)mm*(1273 2.0)mm
Touch Size: (1739.4 2.0)mm*(12294 2.0)mm
Projection Size: (1656.6 2.0)mm*(12294 2.0)mm
Aspec Ratio: 4:3
Shortcut keys: Double side 22 shortcuts
Luminous Transmission : >92% (100% with no glass)
Touch Resolution: Without Driver: 32768*32768
Touch Response Time: less than 6ms
Touch Accuracy: < Imm
Position Precision: < 0.1mm
Cursor Speed: 180 dot/s
Touch Input Method: Touch by finger or any non-transparent objects
Refresh Rate: > 100Hz
Power Supply Mode and Interface: USB cable is enough
Working Voltage: DC 5.0V 5%
Average Current: < 200mA
Interactive-Whiteboard: < 1.0W
LED Lifetime: 60000 hours
Humidity: Up to 90% RH from 0° C to +40" C, non-condensing
Temperature Range: Working :-10°C ~ 50C Storage:-20'C ~60C
Temperature Range: Yes
Firmware Upgrade: USB Upgrade: Windows 8. Windows 7
Support OS: Windows10, Windows8, Windows7, Andriod WindowsXP MacOS.
Accessory Box: Yes, include the wall bracket, cd, user manual, 2 whiteboard pen
Packing Size: (1850 4.0) mm* (1335 4.0) mm * (70 40) mm
Net Weight: (15 2kg)
Gross Weight: (20 2kg)
Certification: CF, FCC, RoHS
Warranty: 1 year warranty standard
